Product Technical Specification
| Brand | Gigabyte |
| Model | H410M H |
| Chipset | Intel H470 |
| Supported CPU | 10th/ 11th Gen Intel Core processor |
| CPU Socket | LGA1200 |
| Memory Type | DDR4 |
| Memory MHz | 3200/ 2933/ 2666/ 2400/ 2133 MHz |
| Memory Channel | Dual |
| Memory Slot | 2 |
| Memory Max. | 64GB |
| Graphics Chipset | Intel HD Graphics support |
| HDMI Port | 1 |
| D-Sub Port | 1 |
| Audio | Realtek audio CODEC, High Definition Audio |
| Audio Channel | 2/4/5.1/7:1 Channel |
| LAN Chipset | Intel GbE LAN Chip (1 Gbit/ 100 Mbit) |
| Expansion Slots | 1 X PCI Express X16 slot, running at X16 2 X PCI Express X 1 slots |
| Storage Interface | 1 X M.2 Connector (Socket 3, M Key, type 2242/2260/2280 Sata and PCIe x4/ x2 SSD Support) 4 X Sata 6Gb/s connectors |
| USB | 2 X USB 3.2 Gen 1 Port (2 ports on the back panel, 2 ports available through the internal USB headers) 6 X USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB headers) |
| Internal I/O Connectors | 1 X 24-pin ATX main Power connector 1 X 8-pin ATX 12V Power connector 1 X CPU fan header 1 X system fan header 1 X RGB LED strip header 4 X Sata 6Gb/s connectors 1 X Front panel header 1 X front panel audio header 1 X USB 3.2 Gen 1 header 1 X USB 2.0/1.1 header 1 X serial port header 1 X Clear CMOS jumper 1 X Trusted Platform Module (TPM) header |
| Form Factor | Micro ATX Form Factor, 22.6cm X 17cm |
| Support Operating System | Windows 10 64 Bit/ 11 64 Bit |
| Warranty | 3 Years |
